W02-358-3000 Firestone Style 1M1A-0 Cab Air Shock Absorber 1/8NPT Seat Air Spring

Ürün ayrıntıları:

Menşe yeri:	Guangdong, Çin
Marka adı:	GUOMAT
Sertifika:	ISO/TS16949:2009
Model numarası:	G3000

Ödeme & teslimat koşulları:

Min sipariş miktarı:	6 adet
Fiyat:	$39.9-49.9/pc
Ambalaj bilgileri:	Güçlü karton kutusu veya müşterilerin ihtiyaç duyduğu gibi
Teslim süresi:	2-8 iş günü
Ödeme koşulları:	T/T, Western Union, L/C
Yetenek temini:	Haftada 1000pcs

İletişim

Detaylı ürün tanımı

Öğe Adı:	Kabin Hava Amortisörü	Garanti:	1 yıl garanti
Kalite:	% 100 test edildi	Konum:	Sürücü Koltukları İçin
Ateş taşı:	W02-358-3000	Hava takımı:	1/8NPT
Saplama malzemesi:	Plastik	Renk:	Siyah
Vurgulamak:	Firestone cab air shock absorber , 1M1A-0 seat air spring , 1/8NPT cab shock absorber

W02-358-3000 Firestone Style 1M1A-0 Cab Air Shock Absorber 1/8NPT Seat Air Spring

Product Description

Product: Sleeve Air Bags
For Truck: Cab Seats for General Trucks
Brand: GUOMAT
Model No.: G3000
Material: Plastic
Warranty: 12 Months
Condition: New
Items Included: Mount
Universal Fitment: Yes
Packing: Neutral Packing or Customization

OEM Reference Number

Firestone OEM Part Number: W02-358-3000, W02 358 3000, W023583000

Firestone Bellows Part Number: 1M1A-0, 1 M1A-0, 1 M 1A-0

Other Firestone Models with the Same Style 1M1A-0:
Firestone Assembly Part Number: W02-358-3001, W02 358 3001, W023583001
Firestone Assembly Part Number: W02-358-3005, W02 358 3005, W023583005

GUOMAT G3000 Technical Data

5/16-18 Threaded Hole
2.88 Top Cover Plate Diameter
3.4 Max Outer Diameter
1/8NPT Air Inlet
2.4 Bottom Diameter
3.5 Max.Height
1.5 Min.Height

Volume @ 100PSIG=9.2in³ | Natural Frequency
Gage Pressure(PSIG)	Load(lbs.)	Spring Rate(lbs./in.)	CPM	HZ
40	210	336	235	3.92
60	330	467	224	3.73
80	450	619	220	3.67
100	570	740	214	3.57

Advantages of Installing GUOMAT G3000 Air Springs

Infinitely Adjustable Suspension Stiffness: Adjust at any time according to different situations:
- Single Ride: Lower air pressure for softer, more comfortable experience
- Dual Ride/Carrying Heavy Loads: Increase air pressure for strong support
- Highway Cruise: Increase air pressure for greater stability
- City Driving: Lower air pressure for better bump absorption
Improved Handling and Stability: Reduces body roll and sway at high speeds
Maintaining Ride Height: Prevents sag under heavy loads
Relatively Easy Installation: DIY-friendly upgrade kit
