FT 330-29 413 Contitech Triple Convoluted Air Spring 64560 Air Bags For Vibratory Grinding Machine

Ürün ayrıntıları:

Menşe yeri:	Guangdong, Çin
Marka adı:	GUOMAT
Sertifika:	ISO/TS16949, ISO9001
Model numarası:	3B330-29

Ödeme & teslimat koşulları:

Min sipariş miktarı:	5
Fiyat:	USD89.9-99.9/PC
Ambalaj bilgileri:	Güçlü Karton Kutu veya Müşterilerin Gereksinimi Olarak
Teslim süresi:	5-8 iş günü
Ödeme koşulları:	L/C, D/A, D/P, Western Union
Yetenek temini:	1000 adet/hafta

İletişim

Detaylı ürün tanımı

Yay Malzemesi:	Kauçuk ve Çelik	Körük Türü:	Üç Katlı
İşlev:	Şoku Azaltın	Kalite:	-40℉ ila 185℉（-40°C ila 85°C）
Durum:	Yepyeni	Contitech:	FT330-29 413
Ateş taşı:	W01-358-8032	diğer isim:	Endüstriyel Hava Yastığı
Vurgulamak:	Contitech triple convoluted air spring , Industrial air bags for vibratory grinding , FT 330-29 413 air spring

FT 330-29 413 Contitech Triple Convoluted Air Spring 64560

High-performance air bags designed specifically for vibratory grinding machines, providing superior vibration isolation and operational stability.

Product Overview

Industrial air springs are robust, flexible rubber air bladders primarily utilized in machinery and equipment, specifically designed to isolate vibrations, lift heavy loads, or adjust height.

Technical Specifications

Manufacturer: GUOMAT
Model Number: 3B330-29
Warranty: 12 Months
Material: Rubber and Steel
Convolutions: 3
Application: Industrial Machinery

OEM Cross-Reference Numbers

Brand	Part Numbers
Contitech	64560, FT330-29 413, FT 330-29 413, FT330-29 413 64560, FT 330-29 413 64560
Firestone	Style 38, W01-358-8032, W01 358 8032, W013588032
Goodyear	3B12-319, 3B 12-319, Flex 578933100
Other Brands	Fleetpride AS8032, Taurus 6334, Triangle AS-4413, TRP AS80320, Automann AS8032

Manufacturer	Original Part Number
Hendrickson	S-12405
Spring Valley	AS-4413
Ridewell	1003588032C

Application in Vibratory Grinding Machines

In modern laboratory and industrial processing systems, air springs are widely used in vibratory sample grinding machines to improve vibration isolation, operational stability, and equipment lifespan. Compared with traditional rubber mounts or metal springs, air springs provide more flexible shock absorption and better dynamic performance during high-frequency vibration operation.

Benefits of Air Springs in Vibratory Grinding Applications

Vibratory grinding machines generate continuous high-frequency vibration during operation. Without proper vibration isolation, excessive vibration can cause multiple issues:
