W01-358-7286 Firestone Industrial Air Spring Style 312 Triple Convoluted Air Bag Actuators

W01-358-7286 Firestone Industrial Air Spring Style 312 Triple Convoluted Air Bag Actuators

  • W01-358-7286 Firestone Industrial Air Spring Style 312 Triple Convoluted Air Bag Actuators
  • W01-358-7286 Firestone Industrial Air Spring Style 312 Triple Convoluted Air Bag Actuators
  • W01-358-7286 Firestone Industrial Air Spring Style 312 Triple Convoluted Air Bag Actuators
  • W01-358-7286 Firestone Industrial Air Spring Style 312 Triple Convoluted Air Bag Actuators
W01-358-7286 Firestone Industrial Air Spring Style 312 Triple Convoluted Air Bag Actuators
Ürün ayrıntıları:
Menşe yeri: Guangdong, Çin
Marka adı: GUOMAT
Sertifika: ISO/TS16949:2009
Model numarası: 3H7286
Ödeme & teslimat koşulları:
Min sipariş miktarı: 6 adet
Fiyat: $299.9-399.9/pc
Ambalaj bilgileri: Güçlü Karton Kutu Veya Müşterilerin İhtiyaç Duyduğu Gibi
Teslim süresi: 2-8 iş günü
Ödeme koşulları: L/C,T/T,Western Union
Yetenek temini: 1000 adet/hafta
İletişim
Detaylı ürün tanımı
Yay Malzemesi: Çelik+kauçuk Garanti: 12 Ay, 1 yıl
Şok Emici Türü:: Otomatik mürekkep beslemesi, sabit basınçlı sirkülasyon sistemi Kalite: -40℉ ila 185℉（-40°C ila 85°C）
Örnek: Kabul etmek Ateş taşı: W01-358-7286
Tip: Flanş Hava Yayı Bağlantı Yöntemi: Sürgü
Vurgulamak:

Firestone Industrial Air Spring

,

Triple Convoluted Air Bag Actuators

,

Style 312 Air Spring

W01-358-7286 Firestone Industrial Air Spring Style 312 Triple Convoluted Air Bag Actuators
Product Overview

High-performance triple convoluted air spring actuator designed for industrial applications requiring reliable air suspension systems.

Product Specifications
Brand GUOMAT
Model 3H7286
Type Triple Convoluted Air Spring
Material Rubber and Steel
Warranty 1 Year
Connection Method Bolt
Technical Data
Design Height 13"
Maximum Height 18"
Minimum Height 4.5"
Flange Diameter 15.12"
Number of Bolts 36pcs total
Bolts 3/8-24
Center Distance Between Bolts 13.81"
Maximum Outer Diameter 18.2"
Cross-Reference Part Numbers
FIRESTONE STYLE 312
FIRESTONE W01-358-7286
FIRESTONE W01 358 7286
FIRESTONE W013587286
FIRESTONE WO1-358-7286
FIRESTONE WO1 358 7286
FIRESTONE WO13587286
Ribbed Neck Aluminum Bead Rings (Equal Spacing)
W01-358-7761 / W01 358 7761 / W013587761
WO1-358-7761 / WO1 358 7761 / WO13587761
Ribbed Neck Aluminum Bead Rings (Unequal Spacing)
W01-358-7760 / W01 358 7760 / W013587760
WO1-358-7760 / WO1 358 7760 / WO13587760
Rolled Plate Assembly
W01-358-7286 / W01 358 7286 / W013587286
WO1-358-7286 / WO1 358 7286 / WO13587286
Rubber Bellows Only
W01-358-7914 / W01 358 7914 / W013587914
WO1-358-7914 / WO1 358 7914 / WO13587914
FIRESTONE STYLE 314
W01-358-8003 - Ribbed neck aluminum bead rings (equal spacing)
W01-358-8004 - Ribbed neck aluminum bead rings (unequal spacing)
W01-358-7926 - Rubber bellows only
W01-358-7286 Firestone Industrial Air Spring Style 312 Triple Convoluted Air Bag Actuators 0
