2H130142 GUOMAT Industrial Air Spring M10 Threaded Hole Convoluted Air Lift Bags 90mm Stroke

Ürün ayrıntıları:

Menşe yeri:	Guangdong, Çin
Marka adı:	GUOMAT
Sertifika:	ISO/TS16949:2009
Model numarası:	1B7451

Ödeme & teslimat koşulları:

Min sipariş miktarı:	6 adet
Fiyat:	$89.9-99.9/pc
Ambalaj bilgileri:	Güçlü Karton Kutu Veya Müşterilerin İhtiyaç Duyduğu Gibi
Teslim süresi:	2-8 iş günü
Ödeme koşulları:	L/C,T/T,Western Union
Yetenek temini:	1000 adet/hafta

İletişim

Detaylı ürün tanımı

Öğe:	Tek Katlı Hava Yastıkları	Garanti:	1 Yıl
Malzeme:	Kauçuk + çelik	paketleme:	Kahverengi Karton
Durum:	% 100 Yepyeni	Net ağırlığı:	2.2kg
Ambalaj boyutu:	252525(CM)	Renk:	Siyah
Vurgulamak:	GUOMAT industrial air spring M10 threaded , convoluted air lift bags 90mm stroke , industrial air spring with warranty

2H130142 GUOMAT Industrial Air Spring M10 Threaded Hole Convoluted Air Lift Bags 90mm Stroke

Product Overview

2H130142 GUOMAT Industrial Air Spring M10 Threaded Hole Convoluted Air Lift Bags 90mm Stroke

Product Information

Manufacturer: GUOMAT

Manufacturer Part Number: 2H130142

Single Convolution Air Spring
Natural Bellows
Blind Nuts
M10 Threaded Hole

Technical Parameters

Top flange diameter: 140mm

Top threaded holes: 6pcs XM10

Center distance between top threaded holes: 112mm

Bottom flange diameter: 140mm

Bottom threaded holes: 6pcs XM10

Center distance between bottom threaded holes: 112mm

Maximum outer diameter: 150mm

Natural height: 142mm

Minimum height: 72mm

Maximum height: 162mm

Stroke: 90mm

Carrying Capacity	Installation	0.2 MPa	0.3 MPa	0.4 MPa	0.5 MPa	0.6 MPa	0.7 MPa	0.8 MPa
72 mm	211	319	428	536	647	756	861	1.44
92 mm	176	266	357	448	540	631	722	0.66
112 mm	140	211	285	360	434	506	580	0.86
132 mm	104	158	217	274	332	387	444	0.95
142 mm	80	126	173	219	266	314	361	1.00
162 mm	14	35	55	5	96	117	140	1.14
172 mm					12	20	25	1.17
